Key Features
- Equal diameter outlets for smooth and uniform flow distribution.
- Integrated copper heating coil for strong, uniform welding results.
- Available inSDR11, SDR17 to meet various pressure needs.
- Pressure rating: PN16 (water) / PN10 (gas).
- Compatible with all major HDPE pipe systems and fusion machines.
- Resistant to corrosion, chemical stress, and ground movement.
- Suitable for buried and above-ground piping networks.
Applications
The Electrofusion Equal Tee is widely used in:
- City gas distribution networks
- Potable water pipelines
- Industrial and irrigation systems
- Pipeline renovation or connection projects
- Municipal water supply and drainage systems
- Natural gas and LPG distribution pipelines
- Industrial fluid and chemical transport systems
- Agricultural irrigation networks
- Mining and geothermal piping projects
Our Electrofusion Equal Tees are engineered to perform reliably even under high pressure, making them ideal for long-term buried installations in demanding conditions.
Why Choose Xinda Plastic Pipe Co., Ltd Electrofusion Fitting Series
- Over 24 years of HDPE fittings manufacturing experience
- Complete product lines:Electrofusion Fitting Series、PE/Steel Transition Fitting Series、Socket Joint Series、Butt Fusion Fitting Series
- High-precision copper wire embedding for consistent welding quality
- In-house QC lab ensures every fitting is inspected and batch-traced.
- Comprehensive support for OEM and project supply
- Technical team provides fusion guidance and project support.
Installation Guidelines
- Ensure pipe ends are clean, dry, and cut square.
- Mark the insertion depth and align pipes precisely.
- Use a calibrated electrofusion welding machine following fitting barcode parameters.
- Maintain pressure during the fusion and cooling process.
- Avoid moving the joint until fully cooled.
- The Electrofusion Fitting Series is designed for connecting HDPE (High-Density Polyethylene) pipes through a reliable andleak-proof electrofusion process.
- These fittings use embedded heating elements that, when energized, melt the HDPE surface and create a strong, homogeneous joint between pipes or other fittings.
- Engineered for water, gas, and industrial piping systems, this series offers superior performance, easy installation, andlong-term durability — ensuring system integrity even under demanding operating conditions.
- Using advanced electrofusion technology, it ensures a leak-free, long-lasting joint that meets international standards for safety and performance.Electrofusion of HDPE uses electrofusion fittings which have small copper wires coiled around the inside.
- Electric current is then run through those wires using an electrofusion processor in turn melting the HDPE on the inside of the fitting and the outside of the pipe.
- Electrofusion of HDPE uses electrofusion fittings which have small copper wires coiled around the inside. Electric current is then run through those wires using an electrofusion processor in turn melting the HDPE on the inside of the fitting and the outside of the pipe.
